Item

Parameter

Unit

Rated load

5.0

t

Bucket capacity

3.0

m³

Dumping height

3100

mm

Dumping distance

1274

mm

Max.drawing force

158

kN

Max. traction

156

kN

Dimension

8010×3016×3350

Operating weight

16.5

t

Boom lifting time

≤5.6

s

Total time of three devices

≤9.9

s

Wheelbase

2900

mm

Min. turning radius (bucket outer)

6920

mm

Rated power

±35°

Travel speed

I Gear (Forward/Backward)

0~11.5/16.5

 km/h

II Gear (Forward)

0~38

 km/h

Long boom parameter

Standard bucket

Coal bucket

Bucket capacity

2.7m³

3.5m³

Rated load

4.5t

4.0t

Dumping height

3520mm

3340mm

Dumping distance

1230mm

1380mm

Dimension

8300×3016×3350

8530×3016×3350

Min. turning radius (bucket outer)

7060mm

7080mm

Operating weight

16.6t

16.7
