Item

Parameter

Rated bucket capacity

3.5m³

Rated load

6000kg

Operating weight

20000kg

Min. clearance

467mm

Max. traction

171kN

Max.drawing force

201kN

Boom lifting time

5.7s

Total time of three devices

10.9s

Engine

Model

Cummins QSC8.3

Type

6-cylinder, 4-stroke, electronic injection, turbocharging

Rated power

179kW

Rated rotary speed

2200r/min

Travel speed

Forward/Backward I Gear

6/6km/h

Forward/Backward II Gear

11/11km/h

Forward/Backward III Gear

22/22km/h

Forward IV Gear

36km/h

Tyre model

23.5-25
