Overall dimensions(L×W×H)

 5520×1960×2850mm

 rated weight

 2t

 Dumping clearance

 2350/2700/3000mm

 Dumping reach

 900mm

 Breakout fore

 50KN

 Wheel base

 2200mm

 Tread

 1490mm

 Model

 LR4108G75

 Rated power

 64kw

 Rated speed

 2400r/min

 Ist(F/R)

 6/6km/h

 2nd(F/R)

 24/24km/h

 Total cycling time

 ＜10s

 Tyres

 16/70-20

 Operating weight

 6t
